1500W 2000W laser rust cleaning machine to clean laser rust remover
Machine features:
1. The machine adopts a water-cooled structure with stable performance. Flexible operation and easy to use.
2. Special laser head for cleaning, the cleaning width reaches 300mm. The cleaning intensity is high and the speed is fast. The cleaning focal length reaches 80cm, you can work in a standing state, and it will be easier to work for a long time.
3. Process: Various parameters are visible, the cleaning quality is more perfect, and the penetrating power is high.
4. The parameters are stable and the repeatability is high: as long as the laser power is stable under the determined nozzle air pressure and lens state, the process parameters must be repeatable. The efficiency is greatly improved, while the requirements for the operator are also reduced.
Specification
| MODEL NO. | Fiber Laser Cleaning Machine |
| Fiber Power | 1000W 1500W 2000W |
| Cooling Mode | Water Cooling and Protection System |
| Laser Wave Length: | 1064nm |
| Laser Type | Fiber |
| Cleaning Width | 0-300mm |
| Gross Power | 3-7KW |
| Cleaning preview | Red light |
| Laser Power adjust range | 10-100 % |
| Operating Temperature | 0-45° |
| Operating Humidity: | 5-95% |
Super power cleaning Gun
| Power supply (V) | 220V ± 10% AC 50/60Hz |
| Placement environment | Flat, vibration and shock free |
| Working Environment (℃) | 10 ~ 40 |
| Working environment humidity (%)＜70 |
| Cooling method | Water chiller cooling |
| Suitable Wavelength | 1064 (±10nm) |
| Suitable laser power | ≤ 2000w |
| Reflector | 20*15.2 T1.6 |
| Maximum supported air pressure | 15 bar |
| Focus vertical adjustment range | ± 10mm |
| Spot adjustment range | Line 0~300mm |
| Net Weight | 0.7kg |
How laser to do cleaning work?
1) Powerful, short-pulse, and fast-moving laser pulses act on the target surface to generate tiny plasma ruptures, shock waves, thermal stress, etc., which sublime and evaporate surface materials.
2) The focused laser beam can accurately evaporate surface objects or dirt.
3) Fiber laser cleaning is suitable for metal surfaces. The processed and optimized laser beam will not change the metal properties or damage the laser-treated surfaces. The precisely tuned laser beam only acts on the coating, residue or oxide, and will not harm the underlying surface of the base material.
4) By adjusting other parameters, the laser beam can accurately and easily achieve the required cleaning effect.
Machine parameters
| Model | RL-C1000 | RL-C1500 | RL-C2000 |
| Wavelength | 1080nm | 1080nm | 1080nm |
| Average power | 1000W | 1500W | 2000W |
| Frequency | 20-50 kHz | 50 kHz | 50 kHz |
| Laser type | CW fiber laser | CW fiber laser | CW fiber laser |
| Clean speed | ≤40 M²/Hour | ≤40 M²/Hour | ≤40 M²/Hour |
| Fiber cable length | 10M(others for optional) | 10M(others for optional) | 10M(others for optional) |
| Working life | 100,000 hours | 100,000 hours | 100,000 hours |
| Machine weight | 120kg | 120kg | 120kg |
| Cooling | Water chiller cooling | Water chiller cooling | Water chiller cooling |
| Optional | Manual/Auto | Manual/Auto | Manual/Auto |
| Temperature | 5-40℃ | 5-40℃ | 5-40℃ |
| Beam width | 10-70mm | 10-70mm | 10-70mm |
| Clean speed | Single Phase
220V,50/60HZ | Single Phase
220V,50/60HZ | Single Phase
220V,50/60HZ |
Cleaning samples
